MARANTZ PROFESSIONAL PMD661MKIII

MARANTZ PROFESSIONAL PMD661MKIII

SKU: 248587885588-2-1-1-1-2-1-1-1-1-1-1-1-1-1-1-1-1.

Click on Below Links

The PMD-661 MKIII is a 2-channel handheld solid-state audio recorder. With its uncompromisingly high performance and rugged build quality, the PMD-661 MKIII gives news journalists, court/municipal reporters, public safety personnel, investigators and researchers a professional device that produces accurate, detailed in-field recordings. Plus, its file-encryption function offers the maximum security for sensitive information. It’s ideal for situations where no-compromise audio data capture is required, but bulky equipment and separate microphones are not possible or appropriate.

Technical data:-

Media
Storage: SD/SDHC (SDHC max. size 64 GB)
Recording Formats
WAV: 16/24 bit linear PCM
MP3: MPEG1 Layer III Compression
Recording MP3 Bit Rate (Stereo): 320/256/192/128/64 kbps
Recording MP3 Bit Rate (Mono): 96/64/32 kbps
Sample rate: 44.1/48/96 kHz
Number of channels: 2 (stereo), 1 (mono)
Audio System
Frequency response: 20 – 20kHz (±1dB)
Signal-to-Noise Ratio 65 dB (Mic); 85 dB (Line); IEC-A-weighted
THD (@ 0 VU) 0.08% (Mic); 0.02% (Line)
Dynamic range: 85dB
Inputs
Microphone (XLR) Sensitivity: 1.2 mVrms / 4.2kΩ
Line (1/4” / 6.35 mm) Sensitivity: 0 dbu / 4.2kΩ
Line 2 (1/8” / 3.5 mm) Sensitivity: 500 mVrms / 20kΩ
Outputs
LINE: (2) RCA L/R @ 2.0V/10kΩ
Headphone: ¼” stereo jack @ 16mW/32Ω
Speaker (internal): 450mW/8Ω
Environmental Conditions
Operational temperature: 0 -40°C (32 - 104°F)
Operational humidity: 25 – 85% (no condensation)
Storage temperature: -20 - 60°C (-4 – 140°F)
Power
Power Consumption, Recording & Playback: 4.2W(DC)
Battery life (alkaline): 6 hours (typical)
Phantom power: 48V, 10mA
AC adapter: DA620PMD (included)
Batteries: 4 x AA type alkaline dry cells or 4 x AA type Ni-MH rechargeable batteries
Backup battery: Lithium battery for real-time clock
General
Dimensions: (HWD) 1.4 x 3.7 x 6.5” (36 x 93 x 165mm)
Weight (without batteries): 12.5 oz. (352g)



In The Box

PMD661 MKIII
Power adapter
SD Card
Boundary Microphone (mini-XLR)
XLR-to-Mini-XLR Cable
RCA-to-1/8” (3.5 mm) Audio Cable
USB Cable
Carrying Case
Quickstart Guide
Safety & Warranty Manual
